Catalog No. H5141, F4348
MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1 Adjustable Latch Pin (H6006) +$ 131.40
QTY: 2 Ash Clean Out Cover [2 per unit, each sold separately] (H3111) +$ 74.70
QTY: 3 Auger Motor (H5886) +$ 332.73
QTY: 4 Auger with Lower Bearing (H5921) +$ 715.40
QTY: 5 Blower Snap Switch (H5875) +$ 76.65
QTY: 6 Cast Burn Pot (H5856) +$ 267.31
QTY: 7 Clean-Out Cover Gasket (H5899) +$ 58.95
QTY: 8 Combustion Blower (H6019) +$ 481.30
QTY: 9 Combustion Gasket Housing to Insert (H5900) +$ 58.95
QTY: 10 Combustion Gasket Motor to Housing (H5903) +$ 58.95
QTY: 11 Control Board Access Latch (H5917) +$ 60.90
QTY: 12 Control Board (H5978) +$ 1044.13
QTY: 12A Control Board Low Feed 1.1 ~Old Part # H5141~ (H5979) +$ 1140.82
QTY: 12B Control Board Fuse 3 AMP [5 per pack] (79020) +$ 58.95
QTY: 12C Igniter Fuse 6 AMP [5 per pack] (79021) +$ 58.95
QTY: 13 Neutral Terminal Block with Jumpers (H7422) +$ 214.97
QTY: 14 Convection Blower (H5888) +$ 397.00
QTY: 15 Convection Blower Gasket (H5902) +$ 58.95
QTY: 16 Decorative Nickel Bars [Upper Body] (H5984) +$ 115.80
QTY: 17 Door Handle (H3112) +$ 177.27
QTY: 18 Door with Glass [no trim] (79040) +$ 966.78
QTY: 18A Door Gasket [7 ft per package] (H5904) +$ 100.20
QTY: 19 Flue Restrictor with Hardware (H6037) +$ 177.27
QTY: 19A Flue Clean Out Box (H6021) +$ 372.88
QTY: 20 Hardware Package (H5988) +$ 74.70
QTY: 21 Hopper Door Wire (H5911) +$ 62.85
QTY: 22 Igniter Fuse 6 AMP [5 per pack] (79021) +$ 58.95
QTY: 23 Igniter with Hose Clamp (H6005) +$ 321.52
QTY: 24 Overtemp Switch (H5891) +$ 76.65
QTY: 25 Power Cord ~Old Part # H6004~ (H5660) +$ 78.60
QTY: 26 Proof of Fire Switch (H5887) +$ 141.15
QTY: 27 Right Flange with Controls Access Door (H3128) +$ 177.82
QTY: 28 Right Flange with Controls Access Door - 48 Inches (H6020) +$ 243.01
QTY: 29 Vaccum Line 12 Inch (H5898) +$ 58.95
QTY: 30 Vaccum Switch (H5889) +$ 131.40
QTY: 31 Wiring Harness (H5976) +$ 323.39
QTY: 32 Hopper Switch with Bracket (H8278) +$ Call to Order
QTY: 33 Hopper Switch Wires with Resister (H8279) +$ 428.96
QTY: 34 Outer Top for Hoopper Lid Switch (H8281) *No Longer Available* +$ *0.00*
ACCESSORIES
Item Description (Part Number)
QTY: 35 Black Surround Panel 29 Inches High x 41 Inches Wide (79004) +$ 534.00
QTY: 36 Black Surround Panel 29 Inches High x 48 Inches Wide (79005) +$ 534.00
QTY: 37 Black Surround Panel 33 Inches High x 41 Inches Wide (79006) +$ 534.00
QTY: 38 Black Surround Panel 33 Inches High x 48 Inches Wide (79007) +$ 534.00
QTY: 39 Black Surround Panel 29 Inches High x 41 Inches Wide x 3 Inches Deep (H7232) +$ 470.00
QTY: 40 Heat Kit (79024) +$ 246.00
QTY: 41 30-5/8 Inches x 41 Inches Surround Panel (79026) +$ 534.00
QTY: 42 30-5/8 Inches x 48 Inches Surround Panel (79027) +$ 352.80
QTY: 43 34-5/8 Inches x 41 Inches Surround Panel (79028) +$ 534.00
QTY: 44 34-5/8 Inches x 48 Inches Surround Panel (79029) +$ 534.00
QTY: 45 Black Extended Side Trim (75251) +$ 149.00
QTY: 46 Nickel Extended Side Trim (75063) +$ 73.50
QTY: 46A Gold Extended Side Trim (75062) +$ 149.22
QTY: 47 Black Surround Trim 29 Inches x 41 Inches (H5143) +$ 149.00
QTY: 48 Black Surround Trim 29 Inches x 48 Inches (H5145) +$ 149.00
QTY: 49 Black Surround Trim 33 Inches x 41 Inches (H5144) +$ 149.00
QTY: 50 Black Surround Trim 33 Inches x 48 Inches (H5146) +$ 149.00
QTY: 51 Nickel Surround Trim (75037) +$ 203.91
QTY: 51A Gold Surround Trim (75036) +$ 199.63
QTY: 52 Nickel Surround Trim (75039) +$ 203.91
QTY: 52A Gold Surround Trim (75038) +$ 199.63
QTY: 53 Nickel Surround Trim (75041) +$ 203.91
QTY: 53A Gold Surround Trim (75040) +$ 199.63
QTY: 54 Nickel Surround Trim (75043) +$ 203.91
QTY: 54A Gold Surround Trim (75042) +$ 199.63
QTY: 55 Zero Clearance Kit (79025) +$ 427.00
QTY: 56 Rear Vent Adapter [required for horizontal vent] (H5147) +$ 32.00
QTY: 57 Black Door Trim (79038) +$ 267.00
QTY: 57A Nickel Door Trim (79037) +$ 641.00
QTY: 57B Brushed Nickel Door Trim (79035) +$ 641.00
QTY: 57C Black Nickel Door Trim (79036) +$ 641.00
QTY: 57D Gold Door Trim (79034) *No Longer Available* +$ *0.00*
QTY: 58 Black Grill (79000) +$ 139.00
QTY: 58A Nickel Grill (79002) +$ 192.00
QTY: 58B Brushed Nickel Grill (79022) +$ 213.00
QTY: 58C Black Nickel Grill (79039) +$ 192.00
QTY: 58D Gold Grill (79001) +$ 272.27
QTY: 59 Log Set (H5142) +$ 288.00
QTY: 60 Standard Brick Panel (79030) +$ 139.00
QTY: 61 On/Off Remote with Timer Mode (H8860) +$ 320.00
QTY: 61A REMOTE CONTROL [LCD Stat, thermostat, on/off] ~Old Part # H0251~ (H8861) +$ 427.00
QTY: 61B Remote Control [touchscreen, thermostat, on/off] (H8865) +$ 460.00
QTY: 61C On/Off Remote and Receiver with White Wall Plate (F2236) +$ 149.00
QTY: 61D Thermostat Remote, Alternating Current, RCVR, RT-AC ~Old Part # 70005~ (H8974) +$ 427.00
QTY: 62 Countdown Timer Wall Switch (H8863) +$ 139.00
QTY: 62A Thermostat Wall Switch ~Old Part # H4635~ (H8864) +$ 106.00
QTY: 63 Diagnostic Tool (H6907) +$ 588.00
QTY: 64 Cleaning Brush (12050004) +$ 90.45
QTY: 65 Black Touch-Up Spray (H8159) +$ 72.75
QTY: 66 Front Support (79003) +$ 299.00
QTY: 67 Owners Manual [hard copy] [900139-00] (OMHC-L) +$ 9.99
QTY: 68 Owners Manual [electronic copy] [900139-00] (OMEL-L) +$ 0.00
|
