DIRECT VENT GAS FIREPLACE INSERT (DRI3030TEN) #DRI3030TEN

DIRECT VENT GAS FIREPLACE INSERT (DRI3030TEN)


Item#: DRI3030TEN

Price: $0.00


Order Now

MAIN ASSEMBLY

Item Description (Part Number)

QTY: 1 LOG SET SUPPORT PANEL (H5839) +$130.71

QTY: 2 LEFT FACE HANGING BRACKET WITH MOUNTING SCREWS (H8502) +$254.58

QTY: 3 REFRACTORY PANEL RETAINING BRACKET SET, 1 INCH THICKNESS (H5748) +$46.86

QTY: 4 FLUE COLLAR KIT *No Longer Available* (H8492) +$*0.00*

QTY: 5 AIR INTAKE KIT (H5723) +$195.83

QTY: 6 RIGHT FACE HANGING BRACKET WITH MOUNTING SCREWS (H8501) +$254.58

QTY: 7 LEVELING LEG KIT- TWO LEGS WITH SCREWS (H5727) +$46.86

QTY: 8 DOOR LATCH ASSEMBLY *No Longer Available* (H8500) +$*0.00*

QTY: 9 BLOWER MOUNTING ASSEMBLY (H8503) +$275.94

QTY: 10 FIREBOX DOOR ASSEMBLY WITH GLASS (H8499) +$515.36

QTY: 11 BURNER ASSEMBLY (H6010) +$233.22

QTY: 12 CONTROL PANEL (H8505) +$359.62

QTY: 13 HEAT SHIELD, FAN CONTROL MODULE (H8482) +$229.75

QTY: 15 BLOWER SNAP SWITCH, 160-20 DEGREE (H8483) +$213.64

QTY: 16 POWER CORD (H3077) +$67.43

QTY: 17 BLOWER WITH MOUNTING SCREWS (H8493) +$461.09

QTY: 18 POWER INTLET/ OUTLET JUNCTION BOX ASSY (H8494) +$306.21

QTY: 19 AC POWER ADAPTER (H8006) +$159.93

QTY: 20 4 AA BATTERY HOLDER ASSY [BATTERIES NOT INCLUDED] (H8495) +$218.98

QTY: 21 IGNITION CONTROL BOARD (J7906) +$281.29

QTY: 22 REMOTE RECEIVER, GT/GTMF, REPLACEMENT- FOR MODELS WITH OPTIONAL GT REMOTE CONTROL KIT INSTALLED (H7277) +$288.41

QTY: 22A GT REMOTE RECIEVER WIRING HARNESS, 18 INCHES. FOR MODELS WITH OPTIONAL GT REMOTE KIT INSTALLED ONLY (H8488) +$243.90

QTY: 23 ON/OFF SWITCH, BURNER AND PILOT MODE (H5744) +$46.86

QTY: 24 BLOWER SPEED CONTROL [RHEOSTAT] (H5655) +$73.00

QTY: 25 REMOTE CONTROL, GT, REPLACEMENT- FOR MODELS WITH OPTIONAL GT REMOTE CONTROL KIT INSTALLED KIT ONLY (H8519) +$291.97

QTY: 25A REMOTE CONTROL , GTMT, REPLACEMENT (H7275) +$309.77

QTY: 26 CASSETTE ASSEMBLY NG [IF LP,ALSO REQUIRES H8459 CONVERSION KIT WITH HI/LO REGULATOR] (H8507) +$712.22

QTY: 27 3/8 INCH NPT PIPE NIPPLE, 8 INCHES *No Longer Available* (H8490) +$*0.00*

QTY: 28 AIR SHUTTER TUBE ASSEMBLY *No Longer Available* (H8498) +$*0.00*

QTY: 29 ORIFICE, MAIN BURNER #36 NG (H5924) +$71.14

QTY: 29A ORIFICE, MAIN BURNER, #51 LP (H5925) +$71.14

QTY: 29B ORIFICE, MAIN BURNER, #49 LP (H5929) +$71.14

QTY: 29C ORIFICE, MAIN BURNER 1/8 INCH NG (H5963) +$71.14

QTY: 30 PILOT SHIELD (H8481) +$233.22

QTY: 31 PILOT ASSEMBLY CONVERTIBLE NG OR LP (H8491) +$291.97

QTY: 32 GAS CONTROL VALVE, MANUAL HI/LO REGULATOR, NG [IF LP, ALSO REQUIRES H8457 LP REGULATOR] (H8508) +$386.32

QTY: 32A GAS CONTROL VALVE, AUTO HI/LO REGULATOR NG [IF LP, ALSO REQUIRES H8459 LP REGULATOR] (H8509) +$425.48

QTY: 33 WIRE GROMMET (H5752) +$12.60

QTY: 34 HOOK AND LOOP DOT KITS -4 SETS (H8497) +$181.59

QTY: 35 POWER ADAPTER BOX ASSEMBLY (H8651) +$336.47

QTY: 37 CONVECTION AIR DEFLECTOR (H8650) +$261.70

QTY: 38 BARRIER [ON CONTEMPORARY FAÇADE] (J7510) +$259.92

QTY: 39 FAN CONTROL MODULE (H7274) +$364.96

QTY: 40 PILOT GROUND WIRE (H8484) +$231.44

QTY: 41 WIRE EXTENSION HARNESS FOR SURROUND MOUNTED ON/PFF SWITCH (H8486) +$249.24

QTY: 42 IGNITION CONTROL BOARD WIRING HARNESS 19 INCHES (H8487) +$242.12

QTY: 43 IGNITION CONTROL BOARD AND GTMF REMOTE RECEIVER WIRING HARNESS 18 INCH (H8489) +$293.75

QTY: 44 BLOWER WIRING HARNESS (H8496) +$284.85

QTY: 45 GAS CONVERSION KIT - AUTO HI/LO REGULATOR LP TO NG (H8458) +$102.00

QTY: 46 GAS CONVERSION KIT - AUTO HI/LO REGULATOR NG TO LP (H8459) +$102.00

QTY: 47 GAS CONVERSION KIT - MANUAL HI/LO REGULATOR LP TO NG (H8456) +$102.00

QTY: 45 GAS CONVERSION KIT - MANUAL HI/LO REGULATOR NG TO LP (H8457) +$102.00

QTY: 49 CONTROL VALVE KNOB EXTENSION - MANUAL HI/LO- SIT (H3080) +$14.72

QTY: 50 HIGH DETAIL LOG SET (H5858) +$474.35

QTY: 51 BAG OF GLOWING EMBERS- ROCKWOOL (H5864) +$46.86

QTY: 52 BAG OF EMBERS- VOLCANIC STONE (H5863) +$50.57

QTY: 53 HARDWARE PACKAGE (H5989) +$58.00

QTY: 54 GASKET KIT (H8518) +$178.03

QTY: 55 TOUCH-UP PAINT - METALLIC BLACK (12 OZ AEROSOL) (H8159) +$48.16

QTY: 56 GT REMOTE CONTROL KIT - ON/OFF (AND THERMOSTAT CONTROL) (H8452) +$Call to order

QTY: 57 LP TO NG CONVERSION KIT - MANUAL HI/LO (H8456) +$102.00

QTY: 58 NG TO LP CONVERSION KIT- MANUAL HI/LO (H8457) +$102.00

QTY: 59 LP TO NG CONVERSION KIT -TCC (H8458) +$102.00

QTY: 60 NG TO LP CONVERSION KIT- TCC (H8459) +$102.00

SURROUND TRIM KITS

Item Description (Part Number)

QTY: 61 TRIM/ BLACK 29 INCHES X 41 INCHES (H5143) +$121.00

QTY: 62 TRIM/BLACK 29 INCHES X 48 INCHES (H5145) +$121.00

QTY: 63 TRIM/BLACK 33 INCHES X 41 INCHES (H5144) +$121.00

QTY: 64 TRIM/ BLACK 33 INCHES X 48 INCHES (H5146) +$121.00

QTY: 65 TRIM/ GOLD 29 INCHES X 41 INCHES (75036) +$166.16

QTY: 66 TRIM/ GOLD 29 INCHES X 48 INCHES (75038) +$166.16

QTY: 67 TRIM/GOLD 33 INCHES X 41 INCHES (75040) +$166.16

QTY: 68 TRIM/ GOLD 33 INCHES X 48 INCHES (75042) +$166.16

QTY: 69 TRIM/NICKEL 29 INCHES X 41 INCHES (75037) +$Call to order

QTY: 70 TRIM/ NICKEL 29 INCHES X 48 INCHES (75039) +$Call to order

QTY: 71 TRIM/NICKEL 33 INCHES X 41 INCHES (75041) +$Call to order

QTY: 72 TRIM/ NICKEL 33 INCHES X 48 INCHES (75043) +$Call to order

SURROUND PANEL KITS

Item Description (Part Number)

QTY: 73 29 X 41 BLACK TRIM [ONE PIECE] NO SWITCH (H8520) +$564.85

QTY: 74 29 X 41 BLACK TRIM [INCLUDES BLACK TRIM] NO SWITCH (H8521) +$307.65

QTY: 75 29 X 48 BLACK TRIM [INCLUDES BLACK TRIM] NO SWITCH (H8522) +$430.27

QTY: 76 33 X 41 BLACK TRIM [INCLUDES BLACK TRIM] NO SWITCH (H8523) +$430.27

QTY: 77 33 X 48 [INCLUDES BLACK TRIM] NO SWITCH (H8524) +$430.27

ACCESSORIES

Item Description (Part Number)

QTY: FIREBOX PANEL KITS (Call to Order) +$Call to order

QTY: 78 TAN BRICK (H7979) +$193.00

QTY: 79 RED BRICK (H7980) +$328.51

QTY: 80 ARCHITECTURAL STONE (H7981) +$398.36

QTY: 81 ZEN GARDEN (H8453) +$194.25
QTY:
