MAIN ASSEMBLY
Item Description (Part Number)
QTY: 1- Log Set (74L62) *No Longer Available* +$*0.00*
QTY: 1A- Burner Log Support (H6556) +$485.04
QTY: 2- Nameplate (12L15) +$Call to Order
QTY: 3- Glass Enclosure Front [2 per unit, each sold separately] ~Old Part # H3724~ (H8122) +$493.03
QTY: 3A- Glass End [Side] Panel ~Old Part # H3725~ (H6336) +$539.76
QTY: 45- Front Lintel 40 Right ~Old Part # H3717~ (H6330) +$38.70
QTY: 45A- Front Lintel 40 Left ~Old Part # H3718~ (H6331) +$38.70
QTY: 46- Metal Brick Interior Kit Rear Baffle (LB-99763W) +$Call to Order
QTY: 47- Standard Hood [2 per unit, each sold separately] (97K52) +$239.27
QTY: 47A- Standard Hood 24 (98K95) +$216.84
QTY: 4- Upper Radiant Panel [2 per unit, each sold separately] ~Old Part # H3722~ (H6334) +$158.58
QTY: 4A- Upper Side Radiant Panel ~Old Part # H3723~ (H6335) +$103.75
QTY: 5- Bottom Radiant Panel [2 per unit, each sold separately] ~Old Part # H3732~ (H6342) +$190.67
QTY: 5A- Bottom Side Radiant Panel ~Old Part # H3733~ (H6343) +$185.06
QTY: 6- Top Front Bustle [2 per unit, each sold separately] ~Old Part # H3741~ (H6351) +$127.50
QTY: 6A- Top Side Bustle ~Old Part # H3743~ (H6353) +$133.35
QTY: 7- Bottom Front Bustle [2 per unit, each sold separately] ~Old Part # H3729~ (H6339) +$94.35
QTY: 7A- Bottom Side Bustle ~Old Part # H3731~ (H6341) +$80.55
QTY: 8- Burner Grate (H6556) +$485.04
QTY: 9- Door Hook Latch [4 per unit, each sold separately] (69L21) +$70.80
QTY: 9A- Door Magnet [2 per unit, each sold separately] (69L31) +$70.80
QTY: 10- Gas Burner Rear ~Old Part # H4865~ (H6555) +$485.04
QTY: 11- Gas Burner Front ~Old Part # H4866~ (H6556) +$485.04
QTY: 12- Burner Brass Fitting (13M25) *No Longer Available* +$*0.00*
QTY: 13- Gas Valve Brass Fitting (H2285) +$188.80
QTY: 14- Gas Line Valve to Burner (H4906) +$64.22
MISC. COMPONENTS
Item Description (Part Number)
QTY: 15- Burner Tray Mounting Gasket (19L51) +$205.63
QTY: 16- Burner Support Bracket (H4884) +$72.75
QTY: 17- Venturi Tube Mounting Gasket (43K85) +$194.41
QTY: 18- Relief Plate with Gasket [2 per unit, each sold separately] ~Old Part # 28L10~ (H8042) +$72.75
QTY: 18A- Gas Control Inside Access Panel/ Modesty Panel ~Old Part # H5011~ (H6618) +$137.18
QTY: 19- Flex Gas Line with Shut-Off (93L32) +$209.36
QTY: 19A- Vent Adapter Secure Vent (74L61) +$145.05
QTY: 19B- Vent Restrictor ~Old Part # 81L32~ (H6216) +$72.75
QTY: 20- Venturi/ Air Shutter Front (60L40) +$Call to Order
QTY: 21- Venturi/ Air Shutter Rear (74L92) +$Call to Order
QTY: 22- Air Shutter Rod (H4897) *No Longer Available* +$*0.00*
QTY: 48- Valve Direct Ignition Control Module (H6209) +$502.70
QTY: 51- Lava Rock ~Old Part # 74L76~ (80L42) +$34.00
QTY: 52- Metal Brick Interior Kit (LB-99763V) +$Call to Order
GAS CONTROLS - SIT MILLIVOLT
Item Description (Part Number)
QTY: 23- Gas Train Assembly NG ~Old Part # H4877~ (H6561) *No Longer Available* +$*0.00*
QTY: 23A- Gas Train Assembly LP ~Old Part # H5349~ (H6689) *No Longer Available* +$*0.00*
QTY: 23B- Gas Conversion NG to LP (85L65) +$280.40
QTY: 23C- Gas Conversion LP to NG [Fits Sit Valve Only] (85L72) +$280.40
QTY: 24- Gas Valve NG ~Old Part # 43K07~ (H6209) +$502.70
QTY: 24A- Gas Valve LP (88J53) +$502.70
QTY: 25- Valve Support Bracket ~Old Part # H3739~ (H6349) +$10.95
QTY: 26- Burner Orifice NG # 44 (60J80) +$104.10
QTY: 26A- Burner Orifice LP # 55 (19L52) +$104.10
QTY: 27- Piezo Igniter [This Igniter Is The Round Part That You Would Push to Generate A Spark] [Piezo Wire Part # 56L21 sold separately] (10K86) +$72.75
QTY: 27A- Piezo Igniter Wire (56L21) +$74.70
QTY: 28- Pilot Assembly Sit NG [Includes: Thermopile, Thermocouple, Pilot Tube, Igniter, Igniter Wire, Pilot Housing] [recommend using High Temp Red Silicone] (69L17) +$421.48
QTY: 28A- Pilot Assembly Sit LP [Includes: Thermopile, Thermocouple, Pilot Tube, Igniter, Igniter Wire, Pilot Housing] [recommend using High Temp Red Silicone] (69L18) +$421.48
QTY: 29- Pilot Tube with Fittings (74L56) +$211.23
QTY: 30- Pilot Shield EDPFNM-2,EDPFPM Gas ~Old Part # H3737~ (H6347) +$82.50
QTY: 31- Thermopile (60J79) +$218.71
QTY: 32- Thermocouple (74L57) +$113.85
QTY: 32A- Igniter Electrode & Cable ~Old Part # 74L58~ (H6212) +$106.05
GAS CONTROLS - HONEYWELL ELECTRONIC
Item Description (Part Number)
QTY: 33- Gas Train Assembly NG (H4878) +$839.32
QTY: 33A- Gas Train Assembly LP ~Old Part # H5350~ (H6690) *No Longer Available* +$*0.00*
QTY: 33B- Gas Conversion NG to LP (85L79) *No Longer Available* +$*0.00*
QTY: 33C- Gas Conversion LP to NG [Fits Honeywell Valve Only] (85L86) +$141.75
QTY: 34A- Gas Valve LP (62L19) +$Call to Order
QTY: 35- Valve Support Bracket ~Old Part # H3738~ (H6348) +$10.95
QTY: 36- Burner Orifice NG # 44 (60J80) +$104.10
QTY: 36A- Burner Orifice LP # 55 (19L52) +$104.10
QTY: 37- Pilot Assembly NG [recommend using High Temp Red Silicone] (62L14) +$597.77
QTY: 37A- Pilot Assembly LP [recommend using High Temp Red Silicone] (62L15) +$252.36
QTY: 38- Pilot Tube with Fitting (H4867) +$90.45
QTY: 39- Pilot Shield (H1596) +$90.45
QTY: 40- Piezo Igniter (87L54) +$451.39
QTY: 41- Power Supply ~Old Part # H4910~ (H3943) +$166.06
QTY: 42- Transformer (42J32) +$259.83
QTY: 43- Owners Manual [Hard Copy] (OMHC-L) +$9.99
QTY: 44- Owners Manual [Electronic Copy] (OMEL-L) +$0.00
|
